Digi-Pas DWL3000XY-Bluetooth + PC Sync PRO Software 2-Axis Digital Machinist Level with Bluetooth and PC Sync PRO Software

The Digi-Pas DWL3000XY is a 2-axis digital machinist level designed for precision angle and leveling measurement. It measures in single-axis and dual-axis modes with graphical display support for direct reading and alignment work. It is suited to machine leveling, angular measurement, and related precision setup tasks.

- Measures single-axis angles from 0° to ±90.00° and dual-axis angles from 0° to ±15.00°.
- Switches between single-axis and dual-axis display behavior based on measuring position.
- Uses a digital reading display and target-ball style dual-axis indication to show plane position and higher side.
- Supports Absolute Level and Alternate Zero modes for direct measurement and reference-based comparison.

- Resolution is 0.01° (0.002 in/ft) with repeatability of 0.01°.
- Accuracy is ±0.01° from 0° to ±10.00° and ±0.03° at other angles.
- Includes a color TFT LCD, user self-calibration, and selectable units in degree, mm/M, and in/ft.
- Operates from 4 x AAA batteries or external USB power and includes Vibrometer capability rated at 2.0g.

- Bluetooth connectivity is shown as an optional device feature in manufacturer literature and is identified in the provided raw product data for this configuration.
- PC Sync software is included as Basic Edition in manufacturer packaging documentation.
- The provided raw product data identifies PC Sync PRO Software for this listing configuration.

- Supports machine leveling and alignment workflows requiring single-axis and dual-axis angle measurement.
- Supports remote synchronization and graphical monitoring workflows when Bluetooth sync is enabled.
- Supports precision setup, calibration-related positioning, and continuous angle or vibration monitoring tasks.
