Digi-Pas DWL3000XY 2-Axis Digital Machinist Level Handheld XRF Analyzer for Alloy, Stainless Steel & Aluminum ID

The Digi-Pas DWL3000XY-Bluetooth is a 2-axis precision digital level designed for angle and leveling measurement. It provides single-axis and dual-axis measurement modes with digital readout, alternate zero, and absolute level functions. Bluetooth-enabled sync and graph-based angle and vibration display support alignment and setup tasks in precision work environments.

- Measures in single-axis and dual-axis modes with automatic position detection for the measurement orientation.
- Uses Absolute Level mode to align readings to the device’s maximum specified accuracy through a guided measurement routine.
- Uses Alternate Zero mode to set any angle as a 0.00° reference for relative measurement on a common plane.
- Displays real-time continuous angle data in line graph format through Angle Meter mode on Bluetooth-capable versions.
- Displays real-time vibration magnitude in graph format through Vibro Meter mode on Bluetooth-capable versions.

- Measuring range is 0° to ±90.00° in single-axis mode and 0° to ±15.00° in dual-axis mode.
- Resolution and repeatability are specified at 0.001° (20 μm/M, 0.0002 in/feet).
- Accuracy is specified as ±0.01° from 0° to 10.00° and ±0.03° at other angles in the DWL-3000XY manual.
- Color TFT LCD display, USB power or 4 x AAA battery operation, and user self-calibration support routine field use.
- Housing dimensions are 188 x 62 x 37 mm with approximate weight of 580 g.

- Supports precision leveling and inclination measurement workflows requiring single-axis or dual-axis digital angle readout.
- Supports machine setup and alignment work through remote sync capability and continuous angle display functions on Bluetooth versions.
- Supports vibration monitoring and relative angle referencing during setup and adjustment procedures.
