Wöhler A 450 L with TD 100 Printer Combustion Analyzer Advanced Set

The Wöhler A 450 L is a combustion analyzer configured as the Advanced Set under article number 8177. It measures flue gas values for residential combustion analysis, service work, burner tuning, emission measurement, and pressure measurement. The included TD 100 printer supports printed measurement documentation at the job site.

- Flue gas sampling measures oxygen and carbon monoxide values, enabling combustion analysis for service and maintenance tasks.
- Measured and calculated results support determination of flue gas loss and burner tuning.
- Differential pressure and gas pressure measurement support setup and verification tasks.
- Four-filter technology with filter monitoring protects the measurement path during operation.

- 5" color touchscreen displays up to 14 measured values at a glance.
- Sensor platform supports up to 3 sensors.
- O2 measurement range is 0…21%.
- CO measurement range is 0…5,000 ppm.
- Optional NO measurement range is 0…3,000 ppm.
- Lithium-ion battery provides 6 h service life.
- Wireless LAN, USB, and IR interfaces support connected measurement workflow.

- Residential combustion analysis.
- Service and maintenance tasks.
- Flue gas loss determination, burner tuning, emission control measurements, and differential pressure or gas pressure measurement.

- Advanced Set article number 8177 includes the Wöhler A 450 L analyzer with 5,000 ppm CO sensor.
- Wöhler TD 100 Thermal Fast Printer and thermal paper support on-site printed records.
- Plastic Case MAXI, probes, filters, cones, pressure hose, lithium-ion battery, and USB charger expand field-ready service scope.
